สถานที่กำเนิด:
จีน
ชื่อแบรนด์:
KACISE
ได้รับการรับรอง:
CE
Model Number:
GXseries
|
Spec. |
Value |
|
|
Pressure range |
0~0.1MPa......60MPa; 1bar…600bar; 14.5psi…8700psi 10000MmH20…6118000mmH2O 0.98atm…592stm |
|
|
Load pressure |
1.5times nominal value pressure (1.5Χ) |
|
|
Rupture pressure |
3times nominal value pressure (3χ) |
|
|
Accuracy |
±0.5%F.S, ±1%F.S, ±2%F.S |
|
|
Stability |
Typical value 0.25%F.S, Max.: 0.5%F.S |
|
|
Operating temperature |
-20°C~60°C |
|
|
Medium compatibility |
All Caustic Medium Compatible with 1Cr18Ni9Ti |
|
|
Output signal |
The relay output |
|
|
Power supply |
24Vdc |
|
|
Contact load |
0.5A 125VAC/1A 30VDC |
|
|
Insulation |
>100M Ω@50V |
|
|
Pressure port |
M20×1.5, G1/4, G1/2, R1/2, NPT1/2 |
|
|
Pressure type |
G,S |
Response time: 10ms |
|
EMI/EMC |
EMI: EN50081-1/-2; EMC: EN50082-2 |
|
2. Feature :
Accuracy : 0.5%F.S, 1%F.S, 2%F.S
Adjustable alarm output
With on-site switch indicator
Various pressure range and switch output
3. Application:
Hydraulic control
Petrochemical
Pressure Instruments
Automatic detection system
Machine control
Metallurgical and Chemica
4. Electronic interface and signals definition
|
Electric connection |
|||
|
Color |
Red |
Black |
White |
|
Definition |
Power+ |
Power - |
Common terminal |
|
Color |
Blue |
Green |
Grey |
|
Definition |
Normally Closed |
Normally open |
Shield |
5. Package
|
|
|
|
|
******************************************************************************************************************************************
Question 1
What about the warranty?
Answer,
The normal warranty is 12 months.
Question 2
We want samples first, do you support?
Answer,
Yes, we support samples. It's better for both sides.
