Place of Origin:
CHINA
ชื่อแบรนด์:
KACISE
ได้รับการรับรอง:
CE
Model Number:
GXPS700
วิดีโอ
วิดีโอ
Spec. | Value | ||
Pressure range | 0~0.01MPa......40MPa | ||
Load pressure | 1.5times nominal value pressure (1.5X) | ||
Rupture pressure | 3times nominal value pressure (3X) | ||
Accuracy | ±0.25%F.S, ±0.5%F.S | ||
Stability | Typical value 0.25%F.S, Max. value: 0.4%F.S | ||
Operating temperature | -40°C~85°C | ||
Compensation temperature | -10°C~70°C | ||
Medium compatibility | All Caustic Medium Compatible with 1Cr18Ni9Ti | ||
Electrical performance | 2 wire system | 3 wire system | |
Output signal | 4~20mA | 0~5V | 0~10V |
Power supply | 10~30Vdc | 6~24Vdc/10~36Vac | 11~30Vdc/20~36Vac |
Load pressure | (U-10)/0.02(Ω) | >100kΩ | |
Insulation | >100M Ω@50V | ||
Electrical connection | Connector DIN43650, IP65 | ||
Air plug GX16-7, IP45 | |||
Waterproof outlet, IP68 | |||
Pressure port | M20×1.5, G1/2, G1/4, NPT1/4, NPT1/2 | ||
Response time | 10ms | ||
Certificattion | Intrinsically safe mode E, Isolation explosion proof D, CE | ||
EMI/EMC | EMI: EN50081-1/-2; EMC: EN50082-2 | ||
2. Feature:
1). High performance oiled diffusion silicon within core elements,
4. Application:
1). Atmosphere measure
2). Aviation, spaceflight, navigation
3). Packaging machinery
4). Petrochemical industry
5). Meteorological monitoring
6). Automatic detection system
7). The mine wind pressure test
8). Top floor apartment management
*****************************************************************************************************************
