Place of Origin:
China (Mainland)
ชื่อแบรนด์:
Kacise
ได้รับการรับรอง:
certificate of explosion-proof, CE
Model Number:
KS3ARG02D
วิดีโอ
วิดีโอ
| Performance parameter | KS3ARG-02D | |
| gyro |
range (deg/s) |
±500(triaxial) |
| Zero-bias(deg/s) | ≤±0.1(In 500°/s) | |
| Zero-bias stability(deg/h) | ≤0.5allan deviation | |
| Zero-bias repeatability(deg/s) | ≤0.05 | |
| nonlinearity(%FR) | ≤0.05 | |
| Random walk(°/√h) | 0.15 | |
| Mean time between failures(Kh MTBF) | 10 | |
| Interface characteristic | power(V) | DC5 |
| power dissipation(W @5V DC) | ≤1 | |
| electrical interface | RS422 | |
| data updating rate(can set) | 2000(Hz@460800) | |
| operating environment | operating temperature(°C) | -40~+80 |
| storage temperature(°C) | -55~+85 | |
| Vibration(g @ 20~2000 Hz) | 6.06 | |
| Shock(g , 0.1 ms, 1/2 Sine) | 5000 | |
| physical property | Size(mm) | 45×39×20 |
| Weight(g) | ≤60 | |
Thank you for choosing our Electronic Gyroscope Sensor. We are committed to providing high-quality products and excellent technical support and services to ensure your satisfaction with our product.
If you encounter any technical issues or have any questions regarding our Electronic Gyroscope Sensor, please do not hesitate to contact our technical support team. Our experienced technicians will be happy to assist you and provide solutions to any problems you may encounter.
You can reach our technical support team through the following channels:
Our technical support team is available during our business hours, Monday through Friday, 9am to 6pm (GMT+8).
In addition to technical support, we also offer the following services to ensure that your Electronic Gyroscope Sensor functions at its best:
Please note that additional fees may apply for some of the above services.
All our Electronic Gyroscope Sensors come with a one-year warranty from the date of purchase. This warranty covers any defects in materials or workmanship. If your sensor is found to be defective within the warranty period, please contact our technical support team for further assistance.
Please refer to our warranty policy for more details.
Thank you again for choosing our Electronic Gyroscope Sensor. We are dedicated to providing the best technical support and services to ensure your satisfaction with our product. Please do not hesitate to contact us if you have any questions or concerns.
The Electronic Gyroscope Sensor is a delicate and highly sensitive device, and thus requires careful packaging and shipping to ensure its safe arrival to the customer.
The sensor will be packaged in a sturdy cardboard box to provide protection against any potential damage during transit. The box will be sealed with high-quality tape to prevent any tampering during shipping.
The sensor will be further protected with bubble wrap and/or foam padding to keep it secure and prevent any movement within the box.
Customers will be provided with a tracking number to monitor the status of their shipment.
We take great care in packaging our products and ensuring their safe delivery, but in the rare case that the sensor arrives damaged, please contact our customer service team for assistance.
