Place of Origin:
CHINA
ชื่อแบรนด์:
KACISE
ได้รับการรับรอง:
CE
Model Number:
GXPS400 series
วิดีโอ
วิดีโอ
|
|
GXCZ Series Analog Output |
GXCZ Series Digital Output |
|
Power supply |
24V DC |
|
|
Measuring object |
Liquid level or Interface |
Liquid level or Interface |
|
Measure range |
80~5000mm (Null point can re-mark by USB encoder) |
|
|
Output |
Voltage: 0~5V or 0~10V |
Modbus |
|
Current: 0~20mA or 4~20mA |
||
|
Load capacity |
Voltage output(min) ≥5K&; |
Can read 32 sensors at same time |
|
Current output(max) 600&; |
||
|
Linearity error |
≤±0.05%F.S(min±50μm) |
|
|
Repetitive error |
≤±0.002%F.S |
|
|
Resolution |
Use 16bit D/A convert,0.015%F.S |
5um |
|
Update time |
1ms(stroke≤1000mm) / 2ms(stroke≤3000mm) / 4ms(stroke≤7000mm) |
|
|
Hysteresis |
≤0.002%F.S |
|
|
Operating Temp. |
-40°C~+85°C |
|
|
Temp. coefficient |
≤0.007%F.S/°C |
|
2. Feature:
1).Zero and full scale field adjustable (optional)
2).Structure and reliable: IP67 rating, Exd II CT6 flame-proof certification
3).Convenient debugging, debugging software
4).Multiple output model electric current, voltage, SSI, Profibus
5).Non-contact measurement, zero maintenance
3. Application:
1).Large oil storage tanks
2).Crude oil storage tanks
3).tanker oil theft prevention
4).Level control requires proof of fire
4. Wiring
5. Package
6.Our Services
Please send us emali for more information.
In order to choose the suitable products for you, please send us below information with the feedback.
1. pressure range
2. accuracy
3. output signal
4. power supply voltage
5. pressure port
6. cable length
7. medium
8. temperature range
*****************************************************************************************************************************************
7. Company Information
8.FAQ
Question1
How can I get the proper product?
Answer,
It's better if you can supply us the parameters, such as the power supply you request, the measure range you need.
the output signal you need,
also if you are not familiar with the parameters above ,you can supply us the application field information.
what kind product you used before.
Question 2
What about the warranty?
Answer,
The normal warranty is 12 months.
Question 3
We want samples first, do you support?
Answer,
Yes, we support samples. It's better for both sides.
