สถานที่กำเนิด:
สวิตเซอร์แลนด์
ชื่อแบรนด์:
Endress+Hauser
ได้รับการรับรอง:
CE
| Specification | Details |
|---|---|
| Nominal Diameter Range | DN 4 to 25 (¹⁄₈ to 1) |
| Max. Measurement Error | ±0.25 % o.r. ± 1 to 4 m/s (3.3 to 13 ft/s) |
| Measuring Range | 0.14 to 1.66 l/s (0.035 to 0.44 gal/s) |
| Max. Process Pressure | PN 16 |
| Medium Temperature Range |
Seal material EPDM: -20 to +130 °C (-4 to +266 °F) Seal material Silicone: -20 to +130 °C (-4 to +266 °F) Seal material Viton: 0 to +150 °C (+32 to +302 °F) |
| Ambient Temperature Range | -40 to +60 °C (-40 to +140 °F) |
| Wetted Materials |
Liner: PFA Electrodes: 1.4435 (316L); Alloy C22, 2.4602 (UNS N06022), Tantalum, Platinum |
| Housing Material | 1.4404 (316/316L) - Sensor and Transmitter |
| Degree of Protection | IP66/67, type 4X enclosure |
| Display/Operation | No local operation - Configuration via operating tools possible |
| Outputs | Pulse/frequency/switch output (passive) |
| Digital Communication | Modbus RS485, IO-Link |
| Power Supply | DC 20 to 30 V |
