Place of Origin:
CHINA
ชื่อแบรนด์:
kacise
ได้รับการรับรอง:
CE
Model Number:
KCD602
| Model | KEC601 |
| Measuring range | 0～5000μS/cm |
| Resolution | 1μS/cm |
| Precision | ±1.5%F.S. |
| Working Temperature | 0～65℃ |
| Working Pressure | ＜0.6MPa |
| Power Supply | 12～24VDC ±10% |
| Signal Output | RS-485(Modbus/RTU) |
| Wetted Material | ABS/SUS316L(Default)/PVC |
| Mounting Method | Immersion mounting, 3/4 NPT thread |
| Cable Length | 5 meters, other lengths can be customized |
| Temperature Compensation | Auto temperature compensation(Pt1000) |
| Calibration | Two-point calibration |
| Power Consumption | ＜0.3W@12V |
| Protection Grade | IP68 |
Note: At least 2 cm from the bottom and side walls of the container during installing and testing.
a) Red line - power cord (12 ~ 24V)
b) Black line - ground (GND)
c) Blue line - 485A
d) white line - 485B
e) bare wire - shielded wire
After wiring is completed, it should be carefully checked to avoid incorrect connections before powering up.
Cable specification: Considering that the cable is immersed in water (including sea water) for a long time or exposed to the air, the cable has certain corrosion resistance. The outer diameter of the cable is Φ6 mm and all interfaces are waterproof.
